It simulates the cutting of involute teeth using a gear rack using the rolling-in method and is intended for conducting laboratory classes in the general technical disciplines “Theory of Machines and Mechanisms” and “Technical Mechanics” in the training of mechanical specialists of higher and secondary vocational education. The stand allows you to study the effect […]

The stand consists of a base with a supporting panel on which the crank mechanism under study is placed. A crank is installed on the shaft of the drive gear motor with adjustable rotation speed. The crank is also connected to the rocker, which makes translational movement. The stand provides the ability to set different […]

The stand consists of a base with a supporting panel on which the studied cam mechanism with a rocker arm is placed. One of four replaceable cams with different profiles can be installed on the shaft of the drive gearmotor with adjustable rotation speed. The cam drives a rocker arm located in a vertical plane […]

The complex is designed to determine the moment of inertia of axisymmetric parts. Composition: frame structure; a cartridge for fastening the part under study, installed on the frame structure on an elastic thread; accelerometer; frequency meter with digital display; device for excitation of torsional vibrations. Overall dimensions: 220x220x450 mm

Description. The set of models is intended for use in laboratory workshops and when giving lectures on courses in technical mechanics, applied mechanics, theory of machines and mechanisms. The set includes models of complex machines for various purposes, including a set of standard mechanisms (gear, lever and cam), the joint functioning of which ensures the […]

The operation of the installation is based on the principle of a crank-slider mechanism with variable eccentricity. The installation must consist of a base with two fixed posts installed on it. There should be a crank on one stand, to which the angular scale and the drive handle are rigidly connected. The crank is pivotally […]

The stand must be made in the form of a desktop frame structure, consisting of a base on which a crank rotation mechanism with a vernier and a rocker rotation mechanism with a vernier are placed. A crank must be attached to the crank rotation mechanism, to which a connecting rod is attached, which can […]

The stand must be made in the form of a desktop frame structure, consisting of a load-bearing frame with a front panel attached to it. The following must be fixed on the front panel: an electric motor, a crank mechanism, a brake mechanism, control keys for starting and stopping the electric motor. An electronic device […]

The stand simulates the process of cutting teeth of involute gearing using the bending method and constructing a tooth profile at various displacements of the initial profile The stand allows you to study the influence of machine gear parameters on the geometry of an involute gear using a set of replaceable tool racks with different […]

The installation should be designed to study the simplest methods of dynamic rotor balancing, determine the imbalance of rotating links and eliminate rotor imbalance using corrective masses. The installation should be an experimental model of a balancing machine of the Shitikov system, and consist of a frame with a drum (balanced rotor) mounted on it […]

The stand represents a frame structure on which an electric motor with frequency control and a rotating rotor with two disks are installed to set an arbitrary initial imbalance. The rotor is mounted on vibration-isolated supports, and vibration sensors are installed on the same supports. The stand’s measurement system makes it possible to determine the […]

The stand is designed to teach the basics of balancing rotors in their own supports, aligning shafts and simulating various types of equipment defects consisting of several shafts. Measuring instruments for vibration diagnostics and shaft alignment are not included in the delivery package. Stand composition: – a shaft with a diameter of 20 mm with […]

The stand allows you to determine the mutual runout of shafts and eliminate it by installing calibrated shims under the supports and displacing the supports. The stand consists of a base on which plates are installed, forming base surfaces for stands with shafts. Four supports are provided on the lower surfaces of the posts for […]

The table-top stand is designed for static and dynamic balancing of rotating masses with a given location. Description: The stand must be made in the form of a desktop structure consisting of the following main components: base, rotor with disks, drive, control panel. The rotor must be a shaft on which five aluminum disks at […]

Purpose. The laboratory stand “Force and kinematic analysis of the mechanism” LS-KSA is intended for carrying out a complex of theoretical, practical and laboratory work in the general technical disciplines “Applied Mechanics”, “Theory of Machines and Mechanisms” and “Technical Mechanics” ” Description. The stand must be made in the form of a desktop structure, consisting […]

Purpose. The stand is designed to determine the kinematic parameters of gear multi-stage transmission mechanisms when performing a set of laboratory work in courses in technical mechanics and applied mechanics. Description. The stand represents two and three-stage helical gearboxes. The gearboxes are prepared for easy removal of the cover and are supplied without oil. Discs […]

The stand is designed to study the design and determine the parameters of gears. The stand is a set of gears of various types mounted on stands that allow the wheels to rotate around their axis. The set of measuring tools included in the delivery allows you to determine the basic parameters of gears of […]

Purpose. The automated laboratory complex (hereinafter referred to as ALC) is designed to carry out a set of theoretical, practical and laboratory work in the general technical disciplines “Machine Parts”, “Theory of Machines and Mechanisms” and “Technical Mechanics” in the training of mechanical specialists in institutions of higher and secondary vocational education. Description. The ALC […]
