Oil transportation and storage
Training stand “Pumping stations for petroleum products transportation systems” NFT-NS-010-5LR-01-R
Composition: – supporting frame; – pumps; − absolute pressure sensors; − ball valves; − remote button to start a manual stopwatch; − adjustable valve; − manual pneumatic pump; – liquid filter; − adjustable valve; − liquid tank; − filler neck with cap; − control panel and instrumentation; − pipeline for studying pressure losses along the […]
Training stand “Pumping equipment of oil pumping station with a section of the main oil pipeline” NO-NPS-MNP-016-21LR
The training stand is designed to study the pumping equipment of oil pumping stations, including those with variable speed of the pump shaft, equipment for controlling pressure, flow, level, methods of regulating level, flow and pressure. The control and automation system of the model contains a computer control and information collection system. System parameters are […]
Training stand “Automation of pumping stations for petroleum products transportation systems” NFT-NS-015-17LR-01-PK
The delivery set includes: – educational and research stand; – laboratory table with a folding shelf for a laptop; — laptop; – description of laboratory work; – passport combined with the stand operating manual. The stand allows you to measure the pressure and flow characteristics of pumps and a pumping station based on a combination […]
Standard set of training equipment “Pneumatic proportional-integral regulator of the START system” SPU-PPIRS-021
The composition includes: – pneumohydraulic training stand “Pneumatic proportional-integral regulator of the START system”; — laptop; – compressor; – software for collecting and processing information during laboratory work; – description of laboratory work; – instruction manual for a standard kit; – passport for a standard kit. A standard set of educational equipment is intended for […]
Standard set of training equipment “Pneumatic level gauge for liquid media” PUZhS-021-5LR
The kit is designed to study the design of a pneumatic liquid level detection device with two response zones, its configuration and use in an automatic control system. Determination of its characteristics. Contents of delivery: – training stand “Pneumatic level gauge for liquid media” PUZHS-021-5LR; – compressor; – stand operating manual; – a textbook on […]
Laboratory stand “Oil pumping station and oil storage tank farm”
The laboratory installation is designed to study the design and operating principle of an oil pumping station, as well as the construction of oil storage tank farms. Allows you to configure the operation of the system both automatically and manually, as well as handle emergency situations in the event of failure of one of the […]
Training stand for studying liquid level gauges of various operating principles used in the oil industry, NFT-UZH -14LR-017
The training stand has a frame structure as a base. The frame structure houses a tank made of transparent materials and an operator’s desk with a table top made of laminated chipboard and a vertical panel made of sheet metal. Overall dimensions of the frame structure no more than (length/height/width) 1750/1300/650 mm. A tank made […]
Training stand for studying liquid level gauges of various operating principles used in the oil industry, NFT-UZH -23LR-017
The training stand has a frame structure as a base. The frame structure houses a tank made of transparent materials and an operator’s desk with a table top made of laminated chipboard and a vertical panel made of sheet metal. Overall dimensions of the frame structure no more than (length/height/width) 1750/1300/650 mm. A tank made […]
Stand “Series connection of pumps and their operation on a pipeline network” SGU-NFT-NS-016-4LR
Floor-standing version of the stand. The stand consists of: a frame structure with an instrument panel, a process tank, three centrifugal pumps (pumping unit: plastic and stainless steel), a system of pipelines and taps, a tank for working fluid (water), a frequency regulator for controlling the shaft speed of one of the pumps; flow meter […]
Training stand “Pressure vessels” SRPD-017-8LR
The training stand allows you to study the control and protective equipment of vessels operating under pressure, the conditions for the manifestation of a dangerous factor, safety rules during the operation of vessels, parameters characterizing the state of the working fluid of the vessel, means of monitoring and protecting the operating mode of pressure vessels, […]
Laboratory stand “Dynamic pumps” SGU-NDT-017-9LR
The stand allows you to study the operation of dynamic type pumps: centrifugal with an open impeller, centrifugal with a closed impeller, vortex, measure the pressure and flow characteristics of pumps and a pumping station based on a combination of pump connections, set and determine the pressure and fluid flow at various points in the […]
Training stand “Testing gear pump of lubrication systems” SI-NMSH-015
Designed to study testing methods for NMSh type gear pumps. On the base of the stand, which is a frame structure made of a metal profile, a supply tank of working fluid — oil, a drive motor module, a gear pump of the NMSh type and a pipeline system with taps, pressure sensors and a […]
Training stand “Testing a centrifugal pump” SI-CNS-015
Designed to study methods for testing centrifugal pumps. On the base of the stand, which is a frame structure made of a metal profile, there is a supply tank for the working fluid — water, a drive motor module, a centrifugal pump and a pipeline system with taps, pressure sensors and a flow meter, and […]
Training stand “Repair and testing of centrifugal pump type “K”” RI-NTs-K-019
The training stand allows you to develop practical skills in the repair work of centrifugal pumps using the example of a cantilever centrifugal pump of the “k” type: dismantling from the pump unit, disassembly, troubleshooting, replacement of elements, installation on the unit and testing. The stand includes a drive electric motor with frequency control, a […]
Training stand “Testing and setting up the metering pump” SI-NDZ-015
Designed to study methods for testing ND type metering pumps. On the base of the stand, which is a frame structure made of a metal profile, a supply tank of working fluid, a drive motor module, a dosing pump and a pipeline system with taps, pressure sensors and a device for measuring the dosed volume […]
Training stand “Oil separation”
Training stand “Oil separation” The training stand is designed to study the properties of a liquid medium regarding the dissolution of air in it and the process of degassing the liquid. The stand contains: a container for storing compressed air (pressure up to 0.6 bar); a container in which water is saturated with air under […]
Training stand “Diagnostics of oil and gas pipelines”
It is a section of a pipeline made of transparent material with cameras installed at the edges for launching and retrieving simulators of cleaning and magnetic flaw detection projectiles of the pipeline. A low-pressure compressor is connected to the pipeline through a tap to activate the movement of projectile simulators through the pipeline
Training stand “Repair and testing of valves, taps and gate valves” RI-KZA-019
The training stand allows you to develop practical skills in repair work using the example of valves, taps and gate valves and their testing with the assembly of a simple hydraulic circuit. The stand includes a pumping station, repairable elements and the necessary auxiliary equipment. The stand operates on water. Stand composition. 1. Hydraulic module […]
Stand simulator “Installation and testing of pipeline connections, repair of pipelines” MiI-TS-RTr-020-4LR
The stand should be intended for laboratory work on studying the types of detachable pipeline connections, training in the installation of these connections, repairing pipelines by installing clamps and subsequent hydraulic testing of the tightness of these connections. The work is carried out by a group of 2-3 people. The delivery package should include a […]
Stand simulator “Repair of threaded holes and connections”
The stand is designed to teach methods of repairing threaded holes and connections with students acquiring practical skills. The stand contains: – a bench with a vice; – tabletop drilling machine; – prismatic parts with holes; – a set of screw-in repair inserts; – a set of stepped studs; – a set of extractors; — […]
Training stand-tablet “Repair of keyed joints”
A1 format tablet (841 x 594 mm) with the ability to be used in wall-mounted and desktop versions. The tablet is made on the basis of sanded plywood with a pasted image of structural elements and with a fixed coupling sample with a cut. The tablet is framed using aluminum profile ALU-Frame No. 2a 11-9-20. […]
Educational stand-model “Oil and gas pipeline repair”
It is a set of “defective” pipelines with a diameter of 30…40 mm, on which repairs were carried out in the following ways: — composite coupling installed using KMT technology; — crimp welded coupling; — fillet coupling; — brewing; — surfacing; — grinding; — a pipe with an elliptical bottom and a reinforcing lining. — […]
Educational stand-model “Pipeline repair”
The stand contains a frame structure made of a profile steel pipe with polymer painting, on which a panel with 4 combs is installed for placing samples in two vertical rows, 5 pieces per row. Samples of “defective” pipelines with a diameter of at least 40 mm, a wall of at least 3 mm, a […]
Training stand “Determining the location of a gas pipeline blockage” OMZG-017
It is a training stand containing a pipeline with a length of at least 2 m, a diameter of at least 32 mm, and contains at the inlet and outlet a system of air connection valves and connections between the pipeline cavity and the atmosphere. Blockage of a gas pipeline is simulated by installing a […]
Training stand “Basics of fuel filling station systems” OS-TZS-015-9LR-01
The training stand with educational materials is designed to study the operating processes of fuel filling stations, study the hydraulic characteristics of pipelines and control valves. The stand allows laboratory work to be carried out by a group of 2-3 people. The package includes: – Training stand OS-TZS-015-9LR-01 “Fundamentals of fuel filling station systems”; — […]
Standard set of educational equipment “Fluid mechanics — water hammer” MZh-GU-10-6LR-01
“The standard kit is intended for carrying out 6 experimental laboratory and research works by a group of 2–3 people. Kit includes: –stand “Fluid Mechanics – Water Hammer” MZh-GU-10-6LR-01; — laptop; – description of the software; – stand operating manual. – guidelines for carrying out the following list of laboratory work: 1. Study of pressure […]
