The laboratory ball mill is designed for fine wet grinding of samples of various ores and materials when carrying out practical work within the framework of specialized academic disciplines in educational institutions. The drum is filled with crushed material and balls. When it rotates, the material is crushed as a result of the abrasive, chipping […]

Laboratory tablet press with electric drive and maximum pressure of 5 tons. For pressing laboratory samples (molds up to 8 mm). Laboratory cold isostatic pressing press with electric drive and maximum pressure of 5 tons. With digital display. The tablet press is recommended for frequent use and molds up to 8 mm. The pressure can […]

A drum mill with a rod module (grindability tester) is designed to determine the rod grinding index (RWI) using the F. Bond method, as well as for conducting practical classes on this topic at specialized courses in educational institutions. The set of rods for determining the Bond grindability index includes: — at least 6 rods […]

Heating incubator for drying bulk raw materials materials (sand, crushed stone, slag, ash, etc.) — temperature range — room +5 to +100°C; control device — microprocessor with external graphic LCD display; overall dimensions WxHxD, mm 595x700x600 mm; internal dimensions WxHxD, mm 395x395x360 mm; maximum shelf loading 10 kg/50 kg (optional); maximum chamber load 40 kg/80 […]

Digital dielectric testing apparatus for measuring the electrical strength of various electrical insulating materials. Voltage regulation range (DC/AC) -10-70 kV / 10-50 kV; load current at constant/alternating voltage — 0-10 mA / 0-50 mA; direct measurement of voltage at the load with a relative (absolute) error of no more than 3%; packaging dimensions (LxWxH), 790x300x660mm; […]

Laboratory runners are designed for preparing sand-clay mixtures, as well as for grinding ceramics. Specifications: Maximum loading weight, not less than 6 kg; Runner width, no more than 70 mm; The pressure range is no narrower than 115 to 300; Tank capacity, not less than 0.3 dm3; Speed, not less than 40 rpm; Power supply […]

The laboratory jaw crusher is designed for crushing ores, minerals, slags and other materials of varying strength. A jaw crusher with a complex swing of the jaw, the destruction of the material in which occurs due to compression and shear deformations. The size of the crushed material is determined by the gap between the jaws […]

A mechanical mortar grinds inorganic and organic substances to analytical fineness. Should mix and homogenize powders, suspensions and pastes, and also be used for conducting practical classes on this topic at specialized courses in educational institutions Specifications: The starting material is soft, hard, brittle, pasty; The principle of grinding is pressure, friction; Initial particle size […]

In a vibrating abrader, grinding occurs due to abrasion — simultaneous compression and shear deformation. The size of the crushed material depends on the operating time of the grinder and the physical properties of the material. A platform with a quick-clamping device and six assembled bowls (consisting of a lid, four balls and the bowl […]

In a knife mill, grinding occurs due to cutting — shear deformations. The mill consists of: a feeding hopper, a housing with fixed knives, a rotor with movable knives, a grate, a discharge hopper, a base and an electric motor. An electric motor is installed on the base, to the flange of which a hollow […]

Laboratory muffle furnace for preparing samples for chemical analysis, heating, hardening and firing of materials in an air environment at temperatures of at least 1300°C. Design Features: Durable ceramic muffle; Semi-open heaters on four sides of the chamber; Microprocessor thermostat; Control panel and LED display; Ease of management and control; LED indicators of heater operation […]

The analyzer includes: a vibration drive, a sifting part (consisting of a set of sieves, a tray and a lid) and a device for fastening the sieves. The vibration drive includes: a housing, a platform, springs, unbalances and electric motors with pulleys. The platform is made in the form of a round plate and is […]

The hammer crusher is designed for grinding mineral and technological raw materials with an average hardness of no more than 7 units on the Mohs scale and a melting point of no less than 150 0C, with a moisture content of no more than 10%, at which the grates are not smeared. The crusher can […]

A roll crusher with smooth rolls is designed for crushing brittle materials of varying strength. The operating principle is based on abrasion (simultaneous compressive and shear deformation) of the material between rollers rotating towards each other. The size of the crushed product is determined by the gap between the rolls, the spring force and the […]

The vibration platform is intended for use in laboratory conditions in accordance with GOST 8269.0–97, GOST 12801, GOST 5802, GOST 310.4, GOST 10180, GOST 10181 when conducting practical work within the framework of specialized academic disciplines in educational institutions. Specifications: Load capacity, not less than 100 kg; The frequency of table oscillations is not less […]
