Dimensions 660x850x450 mm Weight, no more than 60 kg Compound: 1. Modules: stand power; food; power meter; power; frequency converter; thyristor converter. 2. Electric machine unit (DC machine, squirrel-cage asynchronous motor, speed sensor). 3. Laptop. 4. Frame. 5. Set of power cables and connecting wires. 6. Technical description. 7. Guidelines for conducting laboratory work.

Dimensions 1060x850x450 mm Weight, no more than 80 kg Compound: 1. Modules: power supply of the stand; nutrition; power meter; additional resistance No. 1; power; frequency converter; thyristor converter; regulators; measuring 2. Electric machine unit (DC machine, squirrel-cage asynchronous motor, speed sensor). 3. Hardware-software measuring complex. 4. Frame. 5. Set of power cables and connecting […]

Dimensions 560x500x350 mm Weight, no more than 30 kg Compound: 1. Monoblock “Servo drive”. 2. Laptop. 3. Frame. 4. Set of power cables and connecting wires. 5. Technical description. 6. Guidelines for conducting laboratory work.

Dimensions 2130x1650x650 mm Weight, no more than 150 kg Compound: 1. Modules: power supply stand; I/O with I/O board; power meter; excitement; frequency converter; three-phase network; speed meter; switch; measuring (2 pcs); single-phase transformers (2 pcs); power lines; synchronization; unit. 2. Electric machine unit (asynchronous motor with squirrel-cage rotor, universal AC machine, encoder). 3. Personal […]

Dimensions 1200x300x300 Weight, no more than 30 kg Compound: 1. Monoblock with power supply, programmable logic controller module and discrete and analog input/output module. 2. Physical model of the control object — “Temperature”. 3. Laptop. 4. Set of power cables and connecting wires. 5. Software (CD). 6. Technical description of the laboratory stand. 7. Guidelines […]

Dimensions 1200x1800x800 mm Weight, no more than 100 kg Compound: 1. Air container with a heater. 2. Air tank cooling fan. 3. Thermocouple (ХК), Thermocouple (ХА). 4. Bimetallic dial thermometer. 5. Copper resistance thermometer. 6. Platinum resistance thermometer. 7. Monoblock “Fundamentals of the theory of automatic control.” 8. Programmable logic controller. 9. Meter-regulator. 10. RS485/USB […]

Dimensions 1200x300x300 Weight, no more than 40 kg Compound: 1. Monoblock with power supply, programmable logic controller module and discrete and analog input/output module. 2. Physical model of the control object — “Pressure”. 3. Laptop. 4. Set of power cables and connecting wires. 5. Software (CD). 6. Technical description of the laboratory stand. 7. Guidelines […]

Dimensions 1800x1200x800 mm Weight, no more than 100 kg Compound: 1. Compressor. 2. Receiver with pneumatic distributor. 3. Overpressure sensor. 4. Digital pressure sensor with analog output. 5. Intelligent pressure sensor with Modbus protocol support. 6. Electric contact pressure gauge. 7. The pressure gauge is exemplary. 8. Monoblock “Fundamentals of the theory of automatic control.” […]

Dimensions 1200x300x300 Weight, no more than 30 kg Compound: 1. Monoblock with power supply, programmable logic controller module and discrete and analog input/output module. 2. Physical model of the control object — “Level”. 3. Laptop. 4. Set of power cables and connecting wires. 5. Software (CD). 6. Technical description of the laboratory stand. 7. Guidelines […]

Dimensions 1200x1800x700 mm Weight, no more than 100 kg Compound: 1. Measuring container (volume 20 l). 2. Technological container (volume 60 l). 3. Electric driven pump with frequency control. 4. Frequency converter. 5. Solenoid valve. 6. Ultrasonic level sensor. 7. Capacitive sensor. 8. Membrane type hydrostatic pressure level sensor. 9. Float level sensor, discrete. 10. […]

Dimensions 1200x300x300 Weight, no more than 30 kg Compound: 1. Monoblock with power supply, programmable logic controller module and discrete and analog input/output module. 2. Physical model of the control object — “Flow”. 3. Laptop. 4. Set of power cables and connecting wires. 5. Software (CD). 6. Technical description of the laboratory stand. 7. Guidelines […]

Dimensions 2100x1600x600 mm Weight, no more than 100 kg Compound: 1. Measuring container (volume 20 l). 2. Technological container (volume 60 l). 3. Electric driven pump with frequency control. 4. Frequency converter. 5. Ultrasonic flow meter. 6. RS485/USB interface converter. 7. Electromagnetic flow meter. 8. Programmable logic controller. 9. SCADA system. 10. Personal computer. 11. […]

Purpose of the stand: the stand is designed to study devices for creating pressure in gases (air is used), instruments for measuring pressure and temperature. The stand is a pneumatic system that allows you to measure air pressure with various devices. It consists of an air compression and supply system, a control experimental receiver, an […]

The scope of delivery should include: – educational and research stand; –laptop; – description of laboratory work; – passport, stand operation manual. The test bench allows you to study the structure of automatic control systems, devices and characteristics of system elements and measure parameters in dynamic mode. The guidelines contain descriptions of 49 laboratory works. […]

The scope of delivery should include: – educational and research stand; –laptop; – description of laboratory work; – passport, stand operation manual. The test bench allows you to study the structure of automatic control systems, devices and characteristics of system elements and measure parameters in dynamic mode. The guidelines contain descriptions of 65 laboratory works. […]

The laboratory complex is designed to study electro-hydraulic drives of tracking and stabilization systems, mechatronic hydraulic modules. Consists of a training and research stand and a computer for automated data collection. Equipped with educational and methodological materials for conducting educational and research work, software that allows you to expand and add the number of laboratory […]

The laboratory complex is designed to study electro-hydraulic drives of tracking and stabilization systems, mechatronic hydraulic modules. It consists of a training and research stand and a computer for programming the controller, controlling the stand and automated data collection. Equipped with educational and methodological materials and software for conducting educational and research work. The stand […]

The laboratory complex is designed to study the static and dynamic characteristics of electrohydraulic drives of tracking and stabilization systems, mechatronic hydraulic modules with a volumetric control method using a hydraulic motor as a drive. Consists of a training and research stand and a computer for automated data collection. Equipped with educational and methodological materials […]

The laboratory complex is designed to study the static and dynamic characteristics of electrohydraulic drives of tracking and stabilization systems, mechatronic hydraulic modules with a reciprocating actuator. Consists of a training and research stand and a computer for automated data collection. Equipped with educational and methodological materials and software for conducting educational and research work. […]

The laboratory complex is designed to study the static and dynamic characteristics of electrohydraulic drives of tracking and stabilization systems, mechatronic hydraulic modules with a comparison of control methods: throttle and volumetric, analog and digital control. Consists of a training and research stand and a computer for automated data collection. Equipped with educational and methodological […]

The laboratory complex is designed to study electro-pneumatic tracking systems for monitoring and managing forces in technological equipment, tracking and stabilization systems, mechatronic electro-pneumatic pneumatic continuous control. Consists of a training and research stand, a power compressor and a computer for automated data collection. Equipped with educational and methodological materials and software for conducting educational […]

The laboratory complex is designed to study electro-pneumatic tracking systems for monitoring and controlling forces in technological equipment, tracking and stabilization systems, mechatronic, electro-pneumatic, pneumatic continuous control. Consists of a training and research stand, a power compressor and a computer for automated data collection. Equipped with educational and methodological materials and software for conducting educational […]

Composition: frame structure, inverted pendulum, three high-speed pneumatic distributors, scales, nozzles of various diameters, pendulum rotation angle sensor, pressure sensor, flow meter, controller, pressure reducing valve, compressor with receiver, ADC board, PC. Laboratory works: 1. Measuring the flow characteristics of the distributor. 2. Measuring the operating time of the distributor. 3. Measuring the flow characteristics […]

The benchtop stand is designed for studying automatic control systems and stabilization systems based on pneumatic drives and a three-degree swinging platform. The stand contains a swinging platform mounted on a spherical support, pneumatic actuators, proportional control valves for each drive, an electronic control and monitoring system with a feedback system. In tracking mode, the […]

The kit allows you to study measuring instruments and control elements of technological parameters of liquid: flow, pressure, temperature. The guidelines contain a description of 26 laboratory works. The stand is a frame structure made of metal with a polymer coating. All stand equipment is mounted on the stand frame structure. Composition of equipment placed […]

Designed to study methods of microclimate control when studying the discipline “Theory of Automatic Control” Contents of delivery: • Laboratory installation • Laptop with pre-installed software • Cable kit • Manual • Guidelines. The laboratory setup includes: • Room model containing: heater, cooler, fan, humidifier, temperature sensor, humidity sensor. • A control unit containing a […]
