07.09. Demo models/layouts
Продукция
07.09. Demo models/layouts
-
Подробнее09.07.00.01 Demonstration model “Open-pit mining of mineral deposits”>
-
Подробнее09.07.00.02 Demonstration model “Roar”>
-
Подробнее09.07.00.03 Demonstration model “Warman 6/4 type slurry centrifugal pump”>
-
Подробнее09.07.00.04 Demonstration model “Installation of heavy-medium enrichment in a heavy-medium cyclone”>
-
Подробнее09.07.00.05 Demonstration model “Installation of enrichment by flotation method”>
-
Подробнее09.07.00.06 Demonstration model “Belt Conveyor”>
-
Подробнее09.07.00.07 Demonstration model “Horizontal centrifuge”>
-
Подробнее09.07.00.08 Demonstration model “Classification hydrocyclone”>
-
Подробнее09.07.00.09 Demonstration model “Radial thickener with central drive”>
-
Подробнее09.07.00.10 Demonstration model “Magnetic separator on permanent magnets”>
-
Подробнее09.07.00.11 Poster “Vibrating dewatering centrifuge”>
-
Подробнее09.07.00.12 Poster “Auger centrifuge”>
-
Подробнее09.07.00.13 Poster “Wedge, gate, and ball valves”>
09.07.00.01 Demonstration model “Open-pit mining of mineral deposits”
The demonstration model represents an industrial site prepared for stripping operations. The model displays in volume a vertical section of the quarry, consisting of a natural (trees, bushes) and industrial landscape on the 1st horizon, developed ledges of the quarry, parts of the serpentine between the steps of the quarry (roads). The model shows the […]
09.07.00.02 Demonstration model “Roar”
The Screen Demonstration Mockup should be designed to demonstrate the basic elements of a vibrating screen. The demonstration model should be scaled down to an objective level of detail and capable of demonstrating the main elements of a typical vibrating screen. The demonstration model should consist of a box, a loading pipe, a sieve, an […]
09.07.00.03 Demonstration model “Warman 6/4 type slurry centrifugal pump”
The layout provides the possibility of large-scale assembly/disassembly of the pump unit to demonstrate the main elements of the internal structure. The model is installed on a specialized mobile floor stand made of rolled steel, coated with protective powder enamel. Overall dimensions of the model assembled with a stand: no less than: 1000x1600x1000 mm.
09.07.00.04 Demonstration model “Installation of heavy-medium enrichment in a heavy-medium cyclone”
The demonstration model “Installation of heavy-medium enrichment in a heavy-medium cyclone” is intended to visually demonstrate the main elements of the external and internal structure of a heavy-medium cyclone, and to conduct theoretical classes in specialized educational institutions. Description: The model is a prefabricated structure on a reduced scale: made of plastic, painted with acrylic […]
09.07.00.05 Demonstration model “Installation of enrichment by flotation method”
Purpose: The demonstration model “Installation of enrichment by flotation method” is intended for visual demonstration of the main elements of the external and internal structure of the flotation machine (the model shows one of the sections of the installation), and for conducting theoretical classes in specialized educational institutions. Description: The model is a prefabricated structure […]
09.07.00.06 Demonstration model “Belt Conveyor”
The model is made using plastic and rubber band at a reduced scale with an objective degree of detail and provides the opportunity to demonstrate the main elements of the internal structure. The model is installed on a specialized mobile floor stand made of rolled steel, coated with protective powder enamel. Overall dimensions of the […]
09.07.00.07 Demonstration model “Horizontal centrifuge”
The model is made of plastic on a reduced scale with an objective degree of detail and provides the opportunity to demonstrate the main elements of the internal structure. The model is installed on a specialized mobile floor stand made of rolled steel, coated with protective powder enamel. Overall dimensions of the model assembled with […]
09.07.00.08 Demonstration model “Classification hydrocyclone”
The demonstration model “Classification hydrocyclone” is intended for visual demonstration of the main elements of the external and internal structure of the classification hydrocyclone, and for conducting theoretical classes in specialized educational institutions. The model is a prefabricated structure on a reduced scale made of plastic, painted with acrylic paint, the type of connection of […]
09.07.00.09 Demonstration model “Radial thickener with central drive”
The demonstration model is designed to clearly demonstrate the main elements of the external and internal structure of a radial thickener with a central drive, and to conduct theoretical classes in specialized educational institutions. The model is a prefabricated structure on a reduced scale made of plastic, painted with acrylic paint, the type of connection […]
09.07.00.10 Demonstration model “Magnetic separator on permanent magnets”
The demonstration layout should be designed to demonstrate the main elements of the magnetic separator. The demonstration model should be made on a reduced scale with an objective degree of detail and provide the ability to demonstrate the main elements of a typical magnetic separator. All elements of the layout must be stationary and securely […]
09.07.00.11 Poster “Vibrating dewatering centrifuge”
The tablet stand is made of HDF with a thickness of at least 3 mm, edged with an aluminum profile. A backing with a color image of the design and operating principle of a vibration dewatering centrifuge is glued onto the HDF. The backing is made of wear-resistant polymer material. Overall dimensions of the tablet […]
09.07.00.12 Poster “Auger centrifuge”
The tablet stand is made of HDF with a thickness of at least 3 mm, edged with an aluminum profile. A backing with a color image of the design and operating principle of a screw centrifuge is glued onto the HDF. The backing is made of wear-resistant polymer material. Overall dimensions of the tablet stand, […]
09.07.00.13 Poster “Wedge, gate, and ball valves”
The tablet stand is made of HDF with a thickness of at least 3 mm, edged with an aluminum profile. A backing with a color image of the design and operating principle of wedge, gate, and ball valves is glued onto the HDF. The backing is made of wear-resistant polymer material. Overall dimensions of the […]
