A set of educational equipment allows you to perform laboratory work in accordance with the requirements of the school physics course curriculum, including: measuring voltage in various parts of the electrical circuit, work and power of electric current, resistance using an ammeter and voltmeter, resistivity of the conductor, emf and internal resistance current source, study […]

Allows you to demonstrate Lenz’s rule. The installation consists of a coil with a ferromagnetic core to create a magnetic field and conductive rings with a cut (2 pcs.) and without (4 pcs.). When you press the “Start” button, the unit turns on briefly. Specifications: • Dimensions of the device (HxWxD): 465x170x170 mm • Powered […]

Main technical characteristics: — dimensions – no more than 1000x250x300 mm; — weight – no more than 1 kg. Set contents: — inclined plane ; — “magic” cylinder; Laboratory work is being carried out on the “Magic” cylinder.

Main technical characteristics: — dimensions – no more than 700x100x150 mm. Set contents: — optical bench; — semiconductor laser; — Web camera; — a set of replaceable diffraction elements (half-plane, hole — 1 pc. each); — adjustable optics holder; — raters; — lens; — frame for replaceable diffraction elements. The laboratory work “Diffraction of light […]

Designed to study the stages of control of optical products and search and study defects in optical glass, as well as to develop methods for checking lenses and prisms. During the inspection of an optical product, it is possible to identify the following technological defects: — stones are small opaque particles separated from the pot […]

Composition: adjustable base, flywheel, set of weights, electronic stopwatch, electronic displacement and time sensors, electronic displacement meter, electromagnetic stopper. The installation makes it possible to determine the moment of inertia of the flywheel and its change by experimental method. The installation is equipped with electronic displacement and time sensors

Composition: laboratory frame with fastening elements, pulse counter block, pulse recording block. Using a gas-discharge counter, the activity of the K40 isotope in the KCl compound is measured. From the measurement data, the half-life is calculated.

Composition: Control unit for heating the filament, a unit with a heated filament and temperature registration. Purpose: Determination of the thermal conductivity coefficient of air.

Composition: optical bench, semiconductor laser, power supply, interference element in a frame, screen, set of raters and adjustable holders. Determination of the radius of curvature of a lens using Newton’s rings in laser radiation.

Designed to study the dependence of radiation power on body temperature using a pyrometer; studying the phenomenon of thermal radiation using the example of measuring the temperature of an incandescent lamp filament with a pyrometer, determining the Stefan–Boltzmann and Planck constants. The instruments necessary for the work are included in the installation.

List of sections studied: Determination of capacitance of a capacitor. Determination of EMF and internal resistance of a current source. Determination of conductor resistivity. Checking the laws of series and parallel connection of conductors. Study of the dependence of power on voltage. Study of the current-voltage characteristics of a semiconductor diode. Study of the structure […]

A virtual laboratory bench is software for a personal computer that allows you to study the design and operating principle of various instruments and technological installations by interacting with their realistic interactive 3D models. An interactive virtual model is an opportunity to easily study phenomena invisible to the naked eye, and devices, mechanisms and systems […]

Allows you to demonstrate the interaction of parallel conductors with currents of the same and opposite directions. Specifications: • Dimensions of the device (HxWxD): 695x250x370 mm • Powered by AC 220V, 50Hz • Current consumption 5A.

Main technical characteristics: — dimensions – no more than 700x700x700 mm; — weight – no more than 8 kg. Set contents: — stand for kinematic mechanism — diamond-shaped kinematic mechanism that allows you to change inertial characteristics of the system during its rotation. — a set of weights (2 chrome-plated steel cylinders); — mechanism for […]

Composition: A block containing a tube with a heater, a sound emitter, a sound speed meter, a temperature meter, a temperature controller, a frequency generator, and a resonance indicator. Purpose: Determination of the ratio of thermal conductivity of air by the resonance method.

Designed to observe how energy is transferred from electrons as a result of inelastic collisions when flying through mercury vapor. The transfer of energy occurs discretely with discretes corresponding to the excitation of certain transitions between energy levels in the mercury atoms by such a collision.

Composition: adjustable base, two physical pendulums, a set of weights, an electronic stopwatch, an electronic angle sensor, an electronic angle meter, an electromagnetic stopper, magnetic traps. The installation makes it possible to study the Law of Conservation of Angular Momentum and Energy during an inelastic collision of two physical pendulums. The unit is equipped with […]

Designed to observe and study the wave properties of matter particles in an experiment on electron scattering on inert gas atoms; to study the scattering of slow electrons on xenon and argon atoms. Allows you to estimate the ionization potential of inert gases using the grid characteristics of lamps, to estimate the size of the […]

Constructing a picture of the field lines and equipotential lines of the electrostatic field under study, determining the strength of the field point under study. The necessary signal sources and measuring instruments are included in the installation. The set includes 3 replaceable plates with different electrode configurations to simulate an electrostatic field with a coordinate […]

Composition: optical bench, halogen lamp in housing, power supply, intensity meter, polarizing filter, rotating stage with photocell, set of glass plates, container. Determination of the degree of polarization depending on the angle of incidence of light on the dielectric in reflected and transmitted light; study of Malus’s law.

Main technical characteristics: — dimensions – no more than 700x100x150 mm. Set contents: — optical bench; — semiconductor laser; — screen ; — a set of one- and two-dimensional diffraction gratings (phase optical gratings with a period of 3-6 μm) — adjustable optics holder; — raters; The laboratory work “Diffraction of light on one- and […]

The emulator simulator is designed to study the stages of manufacturing optical products and study their characteristics, as well as design technologies for optical lenses and prisms. The software part of the emulator simulator allows for familiarization and study of optical products in an unequipped laboratory. Compound: — software package; — PC with licensed software. […]

A virtual laboratory bench is software for a personal computer that allows you to study the design and operating principle of various instruments and technological installations by interacting with their realistic interactive 3D models. An interactive virtual model is an opportunity to easily study phenomena invisible to the naked eye, and devices, mechanisms and systems […]

Main technical characteristics: — supply voltage – 220 V; — dimensions – no more than 200x500x200 mm; — weight – no more than 8 kg. Set contents: — support with an axis; — vertical flat transparent cuvette for liquids — electric cuvette rotation mechanism with speed control The laboratory work “Distribution of liquid in a […]

The geometry of the poles makes it possible to obtain a uniform and non-uniform magnetic field. The direction of the current in the electromagnet coil is changed using a switch. The design of the electromagnet (depending on its position) allows you to obtain a magnetic field with vertically and horizontally located lines of force. The […]

“Physics” (250 topics) a complete set for vocational education;

Experimental determination of the electrical capacitance of a capacitor. Calibration of the current integrator, determination of unknown capacitance, control of the correctness of the calibration result by measuring the capacitance of a battery of two capacitors of known capacity. The necessary signal sources and measuring instruments are included in the installation.
