Electrical engineering and electronics fundamentals
Standard set of educational equipment “Electrical Engineering, Electronics, Electrical Machines and Electric Drives”, computer bench version, E4-2-SK
Overall dimensions (WxHxD): 3420x1620x650 mm. Weight, no more than 300 kg. Compound: 1. Modules of electrical circuits and electronics: power supply 1; 3-phase transformer; multimeters; digital indicator; autotransformer; milliammeters; resistors; reactive elements; function generator; diodes; transistors; single-phase rectifier; operational amplifier; logical elements and triggers; I/O 1. 2. Modules of electrical machines and electric drives: power […]
Standard set of educational equipment “Electrical installation and adjustment of low-current systems”, bench version with laptop, EMiN-SS-SN
The laboratory stand helps to develop electrical installation skills in the areas of: — installation of fire and security systems; — installation of video surveillance systems; — installation of access control systems; — installation of intercom systems. Dimensions (WxHxD), no more than 1060x1750x650 mm. Weight, no more than 110 kg. Compound: 1. Stand power module. […]
Standard set of educational equipment “Electromechanics”, monoblock manual version, EM2-MR
Overall dimensions (WxHxD): 500x400x200 mm. Weight, no more than 30 kg. Compound: 1. Monoblock containing: power supplies; digital current and voltage meters; digital power meter; digital indicator of the shaft rotation speed of the electric machine unit; frequency converter for controlling an asynchronous motor; additional resistance; controls; mnemonic diagrams for studying a single-phase transformer, asynchronous […]
Standard set of educational equipment “Semiconductor devices”, monoblock manual version, PP-MR
Dimensions 400x150x300 mm Weight, no more than 10 kg Compound: 1. Monoblock containing: power supply, sinusoidal signal generator with adjustable amplitude, dial ammeter, multimeter, rectifier diode, Schottky diode, LED, zener diode, bridge rectifier, bipolar transistor, field-effect transistor. 2. Set of power cables and connecting wires. 3. Technical description. 4. Methodological instructions for carrying out laboratory […]
Standard set of educational equipment “Theoretical foundations of electrical engineering”, desktop version with laptop, TOE-NN
Overall dimensions (WxHxD, excluding laptop): ) 1260x610x300 mm. Weight, no more than 30 kg. Compound: 1. Modules: power supply; three-phase power supply; resistors; reactive elements; circuits with distributed parameters; function generator; nonlinear elements; power and phase meter; digital indicators; multimeters; physical foundations of electrical engineering. 2. Hardware-software measuring complex consisting of: input-output module, laptop, software […]
Standard set of educational equipment “Theory of Electric Circuits”, desktop version with laptop, CHPP-NN
Overall dimensions (WxHxD, excluding laptop): 1260x610x300 mm. Weight, no more than 30 kg. Compound: 1. Modules: power supply; three-phase power supply; resistors; reactive elements; nonlinear elements; circuits with distributed parameters; function generator; power and phase meter; measuring; digital indicators; multimeters. 2. Hardware-software measuring complex consisting of: input-output module, laptop, software (DeltaProfi, included in the Unified […]
Virtual bench simulator “Electromechanics”, TS-EMech
The simulator is intended for conducting laboratory and practical training in the courses “Electromechanics”, “Electrical machines and electric drive fundamentals” in higher, secondary and primary vocational educational institutions, training centers for advanced training, etc. The simulator is a virtual analogue of a real “Electromechanics” training stand and allows you to perform laboratory work on transformers, […]
Interactive educational complex “Electrical engineering. Part 3. AC electrical circuits»
The software package is intended both for demonstration by the teacher and for independent practical work by students. Includes structured graphic material in the form of interactive models, an electrical circuit designer with a set of standard circuits for course sections, animated circuits and slides. The complex includes 2 interactive electrical diagrams on the following […]
Laboratory bench “Electrical circuits and fundamentals of electronics”, manual minimodular bench design, with a digital oscilloscope, ETsiOE2-SRMTs
Overall dimensions (WxHxD): 1070x1340x650 mm. Weight, no more than 80 kg. Compound: 1. Power modules, multimeters, function generator, power meter, measuring. 2. Dialing field (analog). 3. Type field (digital). 4. Set of mini-modules “Electrical circuits and fundamentals of electronics”. 5. A set of mini-modules “Fundamentals of Digital Technology”. 6. Digital oscilloscope. 7. Laboratory table. 8. […]
Set of dynamic light tablets “Electric circuits”, ETs-P4-PS
Compound: – dynamic light tablet “DC Electric Circuits” – dynamic light tablet “AC electrical circuits — serial connection”, – dynamic light tablet “AC electrical circuits — parallel connection”, – dynamic light tablet “Electrical circuits of alternating current — parallel connection with a real coil”, – power supply (at least 4 pcs.); – telescopic pointer. Dimensions […]
Standard set of educational equipment “Electrical circuits”, manual bench version, ETs-SR
Overall dimensions (WxHxD): 1060x1350x650 mm. Weight, no more than 80 kg. Compound: 1. Modules: power supply; digital indicators; measuring; multimeters; nonlinear elements; three-phase transformer; resistors; reactive elements; autotransformer; power meter. 2. Laboratory table. 3. Set of power cables and connecting wires. 4. Technical description of the laboratory stand. 5. Guidelines for conducting laboratory work.
Standard set of educational equipment “Electrical Engineering, Electronics, Electrical Machines and Electric Drives”, manual bench version with digital oscilloscope, E4-3-SRTS
Overall dimensions (WxHxD): 1730x1540x650 mm. Weight, no more than 150 kg. Compound: 1. Modules: power supply, multimeters, “Digital indicators”, “Single-phase transformer”, “Electrical machines”, “Additional resistance”, “Frequency converter”, “Thyristor converter”, “Autotransformer”. 2. Monoblock «Regulators». 3. Electric machine unit (DC machine, squirrel-cage asynchronous motor, speed sensor). 4. Desktop analog station «Profi-A». 5. Desktop digital station «Profi-Ts». 6. […]
Standard set of educational equipment “Electromechanics”, tabletop manual version, Emech2-NR
Overall dimensions (WxHxD): 870x630x310 mm. Weight, no more than 50 kg. Compound: 1. Modules: power supply; frequency converter; measuring; multimeters; autotransformer; single-phase transformer; electrical machines, additional resistances; power meter. 2. Electric machine unit. 3. Frame. 4. Set of power cables and connecting wires. 5. Technical description of the laboratory stand. 6. Guidelines for conducting laboratory […]
Standard set of educational equipment “Theoretical foundations of electrical engineering”, computer bench version, TOE-SK
Overall dimensions (WxHxD): 1920x1350x650 mm. Weight, no more than 80 kg. Compound: 1. Modules: power supply; three-phase power supply; resistors; reactive elements; circuits with distributed parameters; function generator; nonlinear elements; power and phase meter; digital indicators; multimeters; physical foundations of electrical engineering. 2. Hardware-software measuring complex consisting of: input-output module, personal computer, software (DeltaProfi, included […]
Standard set of educational equipment “Theory of Electric Circuits”, computer bench version, TPP-SK
Overall dimensions (WxHxD): 1930x1350x650 mm. Weight, no more than 105 kg. Compound: 1. Modules: power supply; three-phase power supply; resistors; reactive elements; circuits with distributed parameters; function generator; nonlinear elements; power and phase meter; measuring; digital indicators; multimeters. 2. Hardware-software measuring complex consisting of: input-output module, personal computer, software (DeltaProfi, included in the Unified Register […]
Standard set of training equipment “Electrician’s Workplace of Category IV”, manual bench version, RMEM-4K-SR
Dimensions (WxHxD) no more than 1300x1600x650 mm Weight, no more than 150 kg Compound: 1. Stand power module. 2. Module «Secondary power supply sources». 3. Laboratory table. 4. Mounting perforated panel. 5. Electric machine unit with an asynchronous motor with a squirrel-cage rotor. 6. Electric machine unit with a two-speed asynchronous motor. 7. Set of […]
Typical set of educational equipment “Electrical engineering and fundamentals of electronics”, bench version, manual minimodular, 2 monoblocks, ETiOE2-M2-SRM
Overall dimensions (WxHxD): 1070x1390x650 mm. Weight, no more than 70 kg. Compound: 1. Monoblock “Electrical circuits and fundamentals of electronics.” 2. Monoblock “Electromechanics”. 3. A set of laboratory mini-modules. 4. Electric machine unit. 5. Laboratory table. 6. Set of power cables and connecting wires. 7. Technical description of the laboratory stand. 8. Methodological instructions for […]
Typical set of educational equipment “Operational amplifiers”, monoblock manual version, OU-MR
Dimensions 400x150x300 mm Weight, no more than 10 kg Compound: 1. Monoblock containing: an adjustable voltage source, a sine wave generator with adjustable amplitude, a digital voltmeter, an inverting amplifier, a non-inverting amplifier, a summing amplifier, a subtracting amplifier, a comparator, a multivibrator. 2. Set of power cables and connecting wires. 3. Technical description. 4. […]
Virtual bench simulator “Theory of electrical circuits”, TC-CHP
The “Theory of Electric Circuits” simulator is intended for conducting laboratory and practical training in higher, secondary and primary vocational educational institutions, training centers for advanced training, etc. The simulator is a virtual analogue of a real training stand “Theory of Electric Circuits” and allows you to conduct virtual laboratory work taking into account real […]
Interactive educational complex “Electrical engineering. Part 4. Three-phase electrical circuits»
The software package is intended both for demonstration by the teacher and for independent practical work by students. Includes structured graphic material in the form of interactive models, an electrical circuit designer with a set of standard circuits for course sections, animated circuits and slides. The complex includes 2 interactive electrical diagrams on the following […]
Set of dynamic light tablets “Electrical engineering and fundamentals of electronics”, ETiOE-P8-PS
Compound: – dynamic light tablet “DC Electric Circuits” – dynamic light tablet “AC electrical circuits — serial connection”, – dynamic light tablet “AC electrical circuits — parallel connection”, – dynamic light tablet “Diodes and thyristors” – dynamic light tablet “Transistors”, – dynamic light tablet “Operational amplifier”, – dynamic light tablet “Voltage Transformers”, – dynamic light […]
Standard set of educational equipment “Circuit with distributed parameters”, monoblock manual version, TsRP-MR
Overall dimensions (WxHxD): 400x140x250 mm. Weight, no more than 3 kg. Compound: 1. Monoblock “Circuit with distributed parameters”, containing: switch voltage, function generator, controls, mnemonic diagram for studying a circuit with distributed parameters. 2. Set of connecting wires and power cable. 3. Technical description. 4. Methodological instructions for carrying out laboratory work.
Standard set of educational equipment “DC Electric Circuits”, monoblock manual version, EC-PT-MR
Overall dimensions (WxHxD): 400x130x250 mm. Weight, no more than 5 kg. Compound: 1. Monoblock «DC Electric Circuits». 2. Set of power cables and connecting wires. 3. Technical description of the laboratory stand. 4. Methodological instructions for carrying out laboratory work.
Standard set of educational equipment “Electrical circuits and electromechanics”, manual bench version, 2 monoblocks, ETsiEM2-M2-SR
Overall dimensions (WxHxD): 1065x1390x650 mm. Weight, no more than 70 kg. Compound: 1. Monoblocks «Electrical circuits», «Electromechanics». 2. Electric machine unit. 3. Laboratory table 4. Set of power cables and connecting wires. 5. Technical description of the laboratory stand. 6. Guidelines for conducting laboratory work.
Standard set of educational equipment “Electrical circuits and fundamentals of electronics”, tabletop manual minimodular version, ETsiOE4-NRM
Overall dimensions (WxHxD): 650x610x300 mm. Weight, no more than 30 kg. Compound: 1. Modules: power supply; multimeters; function generator; measuring; power meter. 2. Typesetting field. 3. Set of minimodules. 4. Frame. 5. Set of power cables and connecting wires. 6. Technical description of the laboratory stand. 7. Guidelines for conducting laboratory work
Standard set of educational equipment “Electrical engineering and fundamentals of electronics”, mini-modular computer bench design, 2 monoblocks, ETiOE2-M2-SKM
Overall dimensions (WxHxD): 1980x1390x650 mm. Weight, no more than 70 kg. Compound: 1. Monoblock “Electrical circuits and fundamentals of electronics.” 2. Monoblock “Electromechanics”. 3. Hardware-software measuring complex consisting of: input-output module, personal computer, software (DeltaProfi, included in the Unified Register of Russian Computer Programs and Databases). 4. A set of laboratory mini-modules. 5. Electric machine […]
Standard set of educational equipment “Electrical Engineering, Electronics, Electrical Machines and Electric Drives”, computer bench version, E4-3-SK
Overall dimensions (WxHxD): 2390x1540x650 mm. Weight, no more than 170 kg. Compound: 1. Modules: power supply, multimeters, “Digital indicators”, “Single-phase transformer”, “Electrical machines”, “Additional resistance”, “Frequency converter”, “Thyristor converter”, “Autotransformer”. 2. Monoblock «Regulators». 3. Electrical machine unit (DC machine, squirrel-cage asynchronous motor, speed sensor) 4. Desktop analog station «Profi-A». 5. Desktop digital station «Profi-Ts». 6. […]
