Description

The educational CNC lathe is designed for students to practically master all stages of production preparation, technological processing modes and manufacture of parts from standard structural materials by turning on a CNC machine.
A machine with a PCNC class CNC computer system (control of the main movement and feed movements, linear, circular and spline interpolation), with a ball screw pair in the feed drive.

Specifications:
— processed materials: metals, plastics, wood;
— maximum spindle speed, rpm: 2500;
— type of spindle speed adjustment: software;
— diameter of the spindle through hole, mm: 21;
— spindle cone: MT3;
— tailstock cone: MT2;
— maximum diameter of the workpiece being processed, mm: 180;
— maximum diameter of the workpiece processed in the centers, mm: 100;
— maximum length of the processed workpiece, mm: 270;
— maximum feed speed, mm/min: 600;
— number of simultaneously controlled coordinates: 2;
— feed drive type: stepper;
— CNC system class: PCNC;
— port for connecting the machine to the computer: USB 2.0;
— maximum total power consumed by the machine, kW: 1;
— largest diameter of the product clamped in the chuck (reverse jaws), mm: 30 (80).

Basic equipment:
— dust-proof and noise-proof cabin with built-in control system and backlight;
— computer simulators of CNC turning and milling machines;
— remote control emulators Sinumeric 828D/840D, Fanuc 0i/31i, HAAS, HEIDENHAIN 320;
— spare parts kit;
— application software for machine control (on digital media);
— user documentation.

Machine dimensions 900*550*480 mm.
Machine weight 120 kg.

Terms of Use:
— air temperature from + 10ºС to + 40ºС;
— air humidity from 25 to 95%.

Machine power supply 220V (1 phase), current frequency 50/60 Hz, current consumption 10A. All power supply circuits of the machine are equipped with protective shutdown devices. The machine body and all metal parts are grounded.
