Description

The complex is designed for filtering through a filter medium with subsequent change in its chemical/physical characteristics of water in the closed life support system of spacecraft. The filtration unit consists of a mechanical sand filter and a chemical filter based on activated carbon.
The filtered water is collected in a stainless steel tank, which provides samples for laboratory analysis.

Compound:
— Frame
— Mineral filter
— Carbon filter
— Pressure gauge
— Centrifugal pump
— Variable area flow meter
— Metering pump
— Feeding tank
— Collection tank for purified water
— Resistance thermometer
— Electronic temperature indicator
— Electronic control panel
— Variable area flow meter sensor
— Pneumatic flow control valve when feeding
— Electro-pneumatic converter
— PID controller based on digital microprocessor
— Guidelines

Specifications:
Dimensions: 2150x750x2000 mm
Weight: 460 kg
