Description

The kit consists of 40 models of various devices and mechanisms for conducting demonstrations using a graphic projector and screen.
— Crank mechanism normal and disaxial
— Crank-slider mechanism with eccentric (extended axle)
— Crank mechanism with swinging slider
— Sine mechanism with vertical and horizontal scenes
— Sine mechanism with inclined rocker
— Crank mechanism with swinging rocker
— Crank mechanism with rotating rocker
— Maltese cross with external gear
— Four-bar hinge mechanism
— Tangent mechanism (performs only oscillatory movements)
— Flat gear mechanism with external gearing
— Ellipsograph mechanism
— Mechanism with output link stops
— Cam mechanism with progressive moving pusher
— Shepping mechanism (3rd class mechanism)
— Y-motor mechanism
— Multiplier mechanism (gear)
— Twin cylinder engine mechanism with indicator diagram
— Approximately guiding Chebyshev hinge mechanism
— Eccentric rocker mechanism
— Blank feed mechanism
— Two-cylinder compressor mechanism
— Mechanism with internal gearing
— Ordinary gear mechanism
— Ordinary reversible gear mechanism
— Stepped gear mechanism
— Elementary planetary gear
— Crank-slider mechanism deaxial
— Complex gear mechanism with planetary stage
— Combine grain cleaning mechanism (3rd class mechanism)
— Six-link linkage water pump
— Six-link piston pump with double rocker linkage
— Six-link lever mechanism of the automatic press with a floating slider
— Six-link lever rocker mechanism of the windrower
— The mechanism of the two-cylinder engine is normal and disaxial
— Device for demonstrating involute gearing
— Four-bar hinge mechanism with extended trunnion
— Device for demonstrating the motion reversal method
— Device for demonstrating the assembly conditions of planetary gearboxes
— The mechanism of a two-cylinder engine with an opposed cylinder arrangement
